F ACTORY T ALK V IEW S ITE E DITION U SER ’ S G UIDE
A–2
• •
•
•
•
 Separate multiple parameters with a space.
 Enclose long file names containing spaces with double quotes when the file names are
used as parameters. For example:
Display PID /P“Temperature Loop 1”
 Enclose area and component names that contain spaces, or are ambiguous, in double
quotes.
An ambiguous area name is one that is the same as another parameter for a command.
For example, AlarmOn “/H” would turn alarm monitoring on in area H; whereas
AlarmOn /H would turn alarm monitoring on with handshaking, in the current area.
 An exclamation mark (!) at the beginning of a new line or immediately after a
semicolon (;) indicates the start of a comment.
Everything between the exclamation mark and the end of the line, or the next
semicolon, is treated as a comment.
 If a command accepts wildcard characters, this is noted in the description of the
command in the Help. The wildcard characters are:
* matches any number of characters, including the backslash (\) and period (.)
? matches any single character
Using tag placeholders in commands
To replace a tag name with its current value when a command is evaluated, enclose the tag
name in dollar signs ($). This creates a tag placeholder in the command.
When using tag placeholders in commands, keep these points in mind:
 Floating point tags can be a maximum of 17 digits long. If the value is longer than
17 digits, it is represented in scientific format.
 The maximum command length is 5000 characters. If tag values substituted for
placeholders in a command cause the command to exceed this length, then the
command will be truncated.
Example 1: A macro using tag placeholders in commands
Display Screen$Tag1$
Display $Tag3$$Tag2$
Valve23=Open
In the first two commands, the tag placeholders Tag1, Tag2, and Tag3 are string tags.
When the macro runs, the tags have the values 1, 2, and ‘Screen,’ respectively.
