Parts of the FactoryTalk View Studio main window
When you create or open an application, its contents are shown in the FactoryTalk View
Studio main window.
Menu bar
The menu bar contains the menu items for the active window. Each editor has its own set
of menus.
Toolbars
The toolbars contain buttons that provide quick access to commonly used menu items.
When you point to a toolbar button, the name of the button is shown in a tooltip.
Diagnostics List
Status bar
Menu bar
Explorer
window
Workspace
Browse devices
on the network.
View the
application.
Toolbar
