F ACTORY T ALK V IEW S ITE E DITION U SER ’ S G UIDE
16–14
• •
•
•
•
Stacking objects
Objects in a graphic display are stacked in the order they are created, with the most
recently created object on top.
To change the order, move objects to the front or back of the stack.
Use Send to Back to move the selected object to the bottom of the stack.
.
Use Bring to Front to move the selected object to the top of the stack.
.
To select the object at the back
 Click the top object once, pause, and then click again. Do not double-click, and do not
move the mouse.
Aligning objects
To line up the tops, bottoms, or sides of objects in a display, align the objects with each
other, or with the display grid.
To do this Click this button or menu item
Align the selected object (or objects) with the left-
most selected object.
Align Left
Align the selected object (or objects) with the
horizontal center of the largest selected object.
Align Center
Align the selected object (or objects) with the
right-most selected object.
Align Right
Send to Back
Select the object. Send the object to back.
Bring to Front
Select the object from behind. Bring the object to front.
