7 • W ORKING WITH NETWORK STATION APPLICATIONS
7–11
•
•
•
• •
7 • Pl
aceh
ol
der
Setting up HMI server properties
After adding an HMI server to a network station application, use the Properties dialog
box to:
 Select the components that will run when the HMI server starts up.
 Specify a macro to run when the HMI server shuts down.
To open the HMI Server Properties dialog box
 In FactoryTalk View Studio or the SE Administration Console, in the Explorer
window, right-click the HMI server icon, and then select Properties.
For details about options in the HMI Server Properties dialog box, click Help.
Starting and stopping HMI server components manually
For the HMI server in a network station application, you can start and stop the server’s
components manually.
To start HMI server components manually
1. In FactoryTalk View Studio or the SE Administration Console, open the network
station application.
2. In the Explorer window, right-click the HMI server, and then select Properties.
3. In the Components tab, click Run Startup Components.
The startup components selected for the HMI server should start running.
