F ACTORY T ALK V IEW S ITE E DITION U SER ’ S G UIDE
15–8
• •
•
•
•
Moving the Diagnostics List
You can detach (undock) the Diagnostics List from the main window, and then move the
Diagnostics List anywhere on the screen.
To undock the Diagnostics List, drag the grab bars at the bottom left of the Diagnostics
List. If you can’t see the grab bars, drag the top edge of the Diagnostics List to make it
larger.
To prevent the Diagnostics List from docking automatically while you move it, hold down
the Ctrl key on the keyboard.
Resizing the Diagnostics List
When the Diagnostics List is undocked, you can make it any size you want. For example,
to view more than one message at a time, make the list larger.
To resize the Diagnostics List, drag an edge or corner until the list is the desired size.
Viewing messages in the Diagnostics List
Messages in the Diagnostics List are preceded by a blue, yellow, gray, or red icon: blue
indicates information, yellow indicates a warning, gray indicates an audit message, and
red indicates an error.
The following illustration shows a warning and an information message:
The types of messages logged to the Diagnostics List depend on how message routing is
set up in the Diagnostics Setup tool.
Clearing messages in the Diagnostics List
To clear messages in the Diagnostics List, use one of these methods:
 To clear the most recent message (at the top of the list), or the selected message, click
Clear.
To detach the
Diagnostics List,
drag the grab bars.
An ellipsis indicates a truncated message.
To view the entire message, resize the Diagnostics List.
