Appendix
Creating cam data with the »Cam Editor«
284
Lenze · Engineer · 2.13 EN - 10/2014
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
For each curve available in the Project tree of the »Cam Editor« the dialog box contains an individual
tab within which the settings for the corresponding curve can be adapted.
General settings
Characteristic Info
Name Name of the curve
• Specifications by the »Cam Manager«.
Scaling
Minimum / maximum
Unit
Value range of the X and Y axes and their units in the Worksheet.
Curve
Number of points
Number of interpolation points for table interpolation
Optimised interpolation If this option is selected, an optimum distribution of points is calculated with the
help of a neuronal network (artificial intelligence). This means that sections that are
only slightly curved (e.g. lines) are represented only by a few interpolation points. In
sharply curved sections, in contrast, many interpolation points are located. As a
result, the curve is of a higher quality.
• Option only activated with »Cam Designer 3« licence upgrade.
Reduced overshoot If this option is selected, the curve objects are replaced with straight lines, if
necessary. As a result, overshooting can be avoided.
• Option only activated with »Cam Designer 3« licence upgrade.
Segmented interpolation If this option is selected, the area for the interpolation is divided into segments with
a definable number of points.
Background layout If this option is selected, the curve remains visible in the chosen colour when you edit
another curve. It is therefore easier for you to keep an eye on dependencies that may
exist between the movements.
Menu command Dialog box / function
FileProject information Project properties
• Summary: optional information (person in charge, topic ...)
• Statistics: filing statistics (date, last amended ...)
FileCam Designer Settings Cam Designer Settings
Activate desired options by setting checkmarks ( ).
• Options
• Attraction between points
• Graphical output to clipboard
