Error messages
PortLogic generator
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.2 PortLogic generator
Checking the ports created
Direction of transfer is not supported {0} [PL0001]
Data length exceeds CAN-PDO length of 64 bits [PL0002]
Port name not definite [PL0003]
Invalid task context: task {0} on runtime system not available [PL0004]
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
Direction of transfer for the indicated port is invalid.  Port editor (ports) ( 155)
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
The data width of the port specified exceeds the
permissible data width for a CAN PDO.
Reduce the data width of the element variables of the
port to a maximum of 8 bytes.
 Defining element variables for "Record" variable type
( 166)
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
The ports of an application have to differ with regard to
their display names.
Allocate definite port names in the PortEditor.
Among other things, port names are used in IEC 61131
programs for enabling the access to ports via IEC 61131
variables.
Adding a port ( 162)
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
An attempt is made to assign a port to a task that is not
available on the device or in the PLC Designer project.
• Open the port editor for the device application
specified.
• Select the task button down on the right in the
application variable field for the port specified.
• A list with available tasks is displayed.
• Select a task from the selection list
• Close the dialog with OK.
If no task is defined in the task configuration of a 9400
PLC Designer program, the operating system
automatically generates a task with the designation
"DefaultTask".
