8.14.4 Establishing an interconnection via an electrical shaft
In »Engineer« the interconnection is created by means of an electrical shaft with the help of a
wizard, which makes all the necessary entries step by step:
1. The specification of a definite designation.
• As several electrical shafts can be implemented within a machine.
2. The assignment of axes to the electrical shaft.
• Because not all axes of a machine necessarily have to be operated from the electrical shaft.
• You can also assign non-cam-capable axes to the electrical shaft so that an interconnection
can for instance be configured from a following axis and several cam axes with different
device series.
3. The assignment of the measuring systems for the corresponding axis and the master value
according to the x/y axis in the worksheet of the »Cam editor«.

Tip!
So-called "wildcards" can also be added to the electrical shaft. A wildcard can be used to
delete real axes from the electrical shaft without the cam data and the measuring systems
being lost.
 Adding placeholders to the interconnection ( 190)
 Assigning an axis to a placeholder ( 191)
 Cancelling existing assignments ( 193)

How to insert an electrical shaft in the project view:
1. In the Project view, either select
• the project element , or
• select an already existing system module, into which the electrical shaft is to be
inserted.
2. Click the icon to insert a machine application.
3. Select the "electrical shaft" in the Machine application dialog box.
4. Confirm selection with OK.
• A wizard is then started which makes all the necessary entries step by step.
