Defining the system functionality
Configuring the terminal assignment
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.8.3 Setting the active level of the digital terminals
For each digital terminal the set active level is displayed:

Click on the or button to alter the active level for the associated digital terminal
from "high-active" to "low-active" or from "low-active" to "high-active".
8.8.4 Displaying the actual status of the terminals
If an online connection to the device is available, the Terminal assignment tab displays the actual
state of the terminals.
Analog inputs/outputs
For the analog inputs/outputs the corresponding actual value is displayed as voltage value:
• The actual values for the analog inputs are displayed in accordance with the selected form of
signal adaptation (offset & gain) in each case.
Digital inputs/outputs
For the digital inputs the current status is visualised by an "LED":
• The status display for the digital inputs considers the selected form of terminal polarity.
Icon Meaning
Digital terminal is "High active"
Digital terminal is "Low active"
Icon Meaning
Off
On
