Lenze · Engineer · 2.13 EN - 10/2014
19
User interface
Project structure (project tree)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.3.1 History of the preselected elements
All elements selected in the Project view during project processing are stored in a "history".
The / buttons in the Toolbar jump to the project element selected previously / next.

Tip!
If the Project tree contains multiple devices, use to return to the component edited last
(e.g. a controller).
• If you click the arrow, , next to the / buttons, a selection list including the elements
selected last is available.
• Every entry is provided in the following form: "project name: element name".
3.3.2 General editing functions in the project view
The following processing functions apply to all elements in the Project view.
 Drag element (cut & paste) ( 19)
 Duplicate element (copy & paste) ( 20)
 Delete element ( 20)
 Rename element ( 20)
Drag element (cut & paste)
1. Select the element to be shifted including all subelements.
2. Click and hold the element with your left mouse button and drag it to the desired position. The
current position of the element is displayed in one of the following manners:
• Highlighting the respective element:
The element to be shifted becomes the sub-element of the highlighted element. This behaviour
corresponds to the following command chain: EditCut, and then EditPaste.

Note!
The history is emptied automatically when the project is closed, i.e. the history is always
empty when you open a project.
