Error messages
CAN generator
248
Lenze · Engineer · 2.13 EN - 10/2014
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.3.5 Ports and PDO
Error in the analysis of the port interconnection [NWCAN0022]
Data width for port exceeded [NWCAN0023]
Catalogue of templates for CAN communication object not found [NWCAN0024]
Error during creation of CAN communication object [NWCAN0025]
Assignment of port to PDO is missing [NWCAN0027]
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
Port-PDO assignment is missing
There is no connection between a port and a process data
object.
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
Maximum 64 bits possible
The data width of the port specified exceeds the
permissible data width for a CAN PDO.
Reduce data width of the element variables of the port to
a maximum of 8 bytes.
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
Catalogue not recorded?
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
Response (Lenze setting printed in bold)
 Error  Warning  Information
Cause Remedy
No connection between a port and a process data object.
