Defining the system functionality
Parameter setting in the »Engineer«
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Structure of the comparison list
After a successful data transmission, the comparison result is shown in a parameter list. The
parameters are arranged in different categories and subcategories which can be selected via the
buttons on the left:
[8-2] Example for a comparison list of two parameter sets
• In the parameter list on the right all parameters of the category/subcategory are shown.
• By clicking the corresponding column header, you can alter the sequence of the parameter
list and change over between ascending and descending order.
• The Parameter list category shows all available parameters of the corresponding device.
• The icon in front of a parameter in the comparison list indicates that the values in column
A differ from value B.
The Result: Value A <> Device value B dialog box is provided with a toolbar in the upper position.
• Click an icon to execute the corresponding function.

Tip!
By using the and keys you can select several parameters at the same time.
Icon Function
Copy selected parameters from column A to column B.
Copy selected parameters from column B to column A.
Copy default setting of a selected parameter to column A.
Copy default setting of a selected parameter to column B.
