Appendix
Export data
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.1.4.2 Export the parameter values of a single device
This command serves to export single or all parameters for a certain device to a file. Result: A file
containing previously selected parameters of one device.

How to export the parameters:
1. Mark the desired device in the project tree
2. Execute the ExportParameter values command via right-click. Alternative call: Menu
command FileExportExport parameters
• Select the desired parameters in field :
3. Go to  area and select the parameters to be exported by clicking the arrow key /undo
the selection by arrow key .
• Select/Undo all visible parameters using the double arrow keys / .
• Multi-selection of parameters shown one above the other:
Hold down the key and highlight the parameters.
• Multi-selection of individual parameters:
Hold down the key and highlight the desired parameters individually.
As an alternative, press the button to open a GDC file which includes the required
parameter selection.
• Field  displays the parameters selected for export.
4. Click OK.
• Select memory location/file format
• Save file
