10 Low-speed ATM configuration
Nortel Secure Router 8000 Series
Configuration -WAN Access
10.8.3 Checking the configuration
Run the following commands to check the previous configuration.
Action Command
Check information about the
PVC.
display atm pvc-info [ interface interface-type
interface-number [ .subinterface ] [ pvc { pvc-name
[ vpi/vci ] | vpi/vci } ] ]
Check information about the
PVC-group.
display atm pvc-group [ interface { interface-type
interface-number [ .subinterface ] } [ pvc { pvc-name
[ vpi/vci ] | vpi/vci } ] ]
Run the display atm pvc-info command. The configuration succeeds when information such
as the PVC status and the interface status appears.
display atm pvc-info
VPI/VCI |STATE|PVC-NAME |INDEX
-------|-----
0/40 |UP |1
|ENCAP|PROT |INTERFACE
__|---- |----- |-------------
|SNAP |None |Atm8/0/0.1 (UP)
Run the display atm pvc-group command. The configuration succeeds when information
such as PVC-group status and PVC number appears.
display atm pvc-group
VPI/VCI PVC_NAME STATE ENCAP PROT INTERFACE GROUP
0/40 1 UP SNAP NONE Atm8/0/0.1(UP) 0/40
10.9 Configuring the service type of PVC
10.9.1 Establishing the configuration task
Applicable environment
In networking, to configure the service type and the related parameters of a PVC (including
the PVCs in the PVC-Group), you need to configure service cbr or ubr of PVC.
Preconfiguration tasks
Before configuring the service types or OAM parameters , complete the following tasks:
• Configuring physical attributes for the ATM interface
• Configuring an IP address and mask for the ATM interface or sub-interface
• Creating a PVC and configuring application modes
Data preparation
To configure the service type of PVC or PVP, you need the following data.
10-28 Nortel Networks Inc. Issue 5.3 (30 March 2009)
