Nortel Secure Router 8000 Series
Configuration -WAN Access
6 PPP and MP configuration
Run the
display interface virtual-template
command to view status of a VT. For example:
Virtual-TemplateO current state : UP
Line protocol current state :UP (spoofing)
Description : NORTEL, Nortel Series, Virtual-TemplateO Interface, Route Port
The Maximum Transmit Unit is 1500 bytes
Internet Address is 10.1.1.2/24
Link layer protocol is PPP
LCP initial, MP opened
Physical is None, baudrate is 64000 bps
QoS max-bandwidth : 64 Kbps
Output queue : (Urgent queue : Size/Length/Discards) 0/50/0
Output queue : (Protocol queue : Size/Length/Discards) 0/1000/0
Output queue : (FIFO queue : Size/Length/Discards) 0/256/0
Last 300 seconds input rate 0 bits/sec, 0 packets/sec
Last 300 seconds output rate 0 bits/sec, 0 packets/sec
0 packets input, 0 bytes, 0 drops
0 packets output, 0 bytes, 0 drops
Run the
display ppp mp
command to check binding information about an MP. For example:
Bundle Multilink, 1 member, slot 6, Master link is Virtual-Template0:1
0 lost fragments, 0 reordered, 0 unassigned, 0 interleaved,
sequence 0/0 rcvd/sent
The bundled son channels are:
Serial6/0/0
6.7 Configuring MP authentication binding through the
VT
6.7.1 Establishing the configuration task
Applicable environment
To obtain broader bandwidth, you can bind multiple PPP links together into a VT.
The binding authentication includes:
•
User name authentication
•
Endpoint discriminator authentication
•
Username and endpoint discriminator authentication.
Currently, MP does not support binding the interfaces of different boards on a router. You can
only bind MP based on the user name.
When you authenticate the MP binding, the process contains two steps as follows:
•
The bound PPP interface must pass the PAP and CHAP authentication.
•
The authenticated object must find the corresponding VT according to the username. If
no VT corresponds to it, the binding cannot succeed.
