Nortel Secure Router 8000 Series
Configuration -WAN Access
6 PPP and MP configuration
QoS max-bandwidth : 64 Kbps
Output queue : (Urgent queue : Size/Length/Discards) 0/50/0
Output queue : (Protocol queue : Size/Length/Discards) 0/1000/0
Output queue : (FIFO queue : Size/Length/Discards) 0/256/0
Last 300 seconds input rate 0 bits/sec, 0 packets/sec
Last 300 seconds output rate 0 bits/sec, 0 packets/sec
0 packets input, 0 bytes, 0 drops
0 packets output, 0 bytes, 0 drops
Run the display ppp mp command. When binding information appears the configuration
succeeds. In the following example, "rtbchap" after "Bundle" is the user name.
Template is Virtual-Templatel
Bundle rtbchap, 1 member, slot 6, Master link is Virtual-Template1:0
0 lost fragments, 0 reordered, 0 unassigned, 0 interleaved,
sequence 0/0 rcvd/sent
The bundled son channels are:
Serial6/0/1
Bundle rtbpap, 1 member, slot 6, Master link is Virtual-Templatel:!
0 lost fragments, 5 reordered, 0 unassigned, 0 interleaved,
sequence 4/5 rcvd/sent
The bundled son channels are:
Serial6/0/0
If the physical interface is bound based on the terminal ID, "67789b06306e" after "Bundle" is
the terminal ID.
Template is Virtual-Template1
Bundle 67789b06306e, 1 member, slot 6, Master link is Virtual-Template1:0
0 lost fragments, 5 reordered, 0 unassigned, 0 interleaved,
sequence 4/5 rcvd/sent
The bundled son channels are:
Serial6/0/0
6.8 Configuring MP binding using the MP-group
6.8.1 Establishing the configuration task
Applicable environment
Configure MP binding using MP-group is more efficient than that using VT.
When configuring MP binding using MP-group, you can only add the interface in the same
slot as the MP-group interface to the MP-group. Only physical interfaces can be added to the
MP-group.
The interfaces added to the MP-group can only be the physical interfaces or the channelized
synchronous serial interfaces instead of logical interfaces.
In MP negotiation, different carriers complements differently.
Issue 5.3 (30 March 2009)
Nortel Networks Inc.
6-33
