7 LAPB and X.25 configuration

Nortel Secure Router 8000 Series

Configuration -WAN Access

# Configure basic X.25.

system-view

[RouterD] interface serial 2/0/0

[RouterD-Serial2/0/0]

link-protocol x25 dte ietf

x25 x121-address 2

x25 vc-range in-channel 10 20 bi-channel 30 1024

shutdown

undo shutdown

x25 pvc 1 ip 1.1.1.1 x121-address 1

ip address 1.1.1.2 255.0.0.0

Step 3

Configure Router B.

# Start the X.25 switching.

system-view

[RouterB] x25 switching

# Configure Ethernet 1/0/0.

[RouterB] interface ethernet 1/0/0

[RouterB-Ethernet1/0/0] ip address 10.1.1.1 255.0.0.0

[RouterB-Ethernet1/0/0] quit

# Configure Serial 2/0/0.

[RouterB] interface serial 2/0/0

[RouterB-Serial2/0/0]

link-protocol x25 dce ietf

x25 vc-range in-channel 10 20 bi-channel 30 1024

shutdown

undo shutdown

x25 xot pvc 1 10.1.1.2 interface serial 2/0/0 pvc 1

shutdown

undo shutdown

Step 4

Configure Router C.

# Start the X.25 switching.

system-view

[RouterC] x25 switching

# Configure Ethernet 1/0/0.

[RouterC] interface ethernet 1/0/0

[RouterC-Ethernet1/0/0] ip address 10.1.1.2 255.0.0.0

[RouterC-Ethernet1/0/0] quit

# Configure Serial 2/0/0.

[RouterC] interface serial 2/0/0

[RouterC-Serial2/0/0] link-protocol x25 DCE IETF

[RouterC-Serial2/0/0] x25 vc-range in-channel 10 20 bi-channel 30 1024

[RouterC-Serial2/0/0] shutdown

[RouterC-Serial2/0/0] undo shutdown

[RouterC-Serial2/0/0] x25 xot pvc 1 10.1.1.1 interface serial 2/0/0 pvc 1

[RouterC-Serial2/0/0] shutdown

[RouterC-Serial2/0/0] undo shutdown

Step 5

Verify the configuration.

7-62
