Nortel Secure Router 8000 Series
Configuration -WAN Access 8 Frame relay configuration
[RouterB] fr switch pvc interface Serial1/0/0 dlci 100 interface Serial2/0/0 dlci 300
group 1
[RouterB-fr-switching-pvc] quit
[RouterB] fr switch pvc1 interface Serial1/0/0 dlci 100 interface tunnel 3/0/1 dlci 300
standby pvc group 1
[RouterB-fr-switching-pvcl] ^i
Step 3 Configure Router C.
# Encapsulate Serial 2/0/0 with FR and configure the interface type as NNI.
system-view
[RouterC] interface Serial2/0/0
[RouterC-Serial2/0/0] link-protocol fr
[RouterC-Serial2/0/0] fr interface-type nni
[RouterC-Serial2/0/0] fr dlci 300
[RouterC-fr-dlci-Serial2/0/0-300] quit
[RouterC-Serial2/0/0] quit
# Encapsulate Serial 1/0/0 with FR and configure the interface type as DCE.
[RouterC] interface Serial1/0/0
[RouterC-Seriall/0/0] link-protocol fr
[RouterC-Seriall/0/0] fr interface-type dce
[RouterC-Seriall/0/0] fr dlci 200
[RouterC-fr-dlci-Seriall/0/0-l00] quit
[RouterC-Seriall/0/0] quit
# Configure GbE 3/0/0 interface and Tunnel 3/0/1.
[RouterC] interface ethernet3/0/0
[RouterC-Ethernet3/0/0] ip address 10.1.1.2 24
[RouterC-Ethernet3/0/0] quit
[RouterC] interface Tunnel 3/0/1
[RouterC-Tunnel3/0/1] source 10.1.1.2
[RouterC-Tunnel3/0/1] destination 10.1.1.1
[RouterC-Tunnel3/0/l] quit
# Create and configure the master and the slave PVCs.
[RouterC] fr switching
[RouterC] fr switch pvc interface Serial1/0/0 dlci 200 interface Serial2/0/0 dlci 300
group 1
[RouterC-fr-switching-pvc] ^it
[RouterC] fr switch pvc1 interface Serial1/0/0 dlci 200 interface Tunnel3/0/1 dlci 300
standby pvc group 1
[RouterC-fr-switching-pvcl] ^it
Step 4 Configure Router D.
# Encapsulate Serial 1/0/0 with FR.
system-view
[RouterD] interface Serial1/0/0
[RouterD-Seriall/0/0] link-protocol fr
[RouterD-Seriall/0/0] ip address 196.1.1.2 255.255.255.0
[RouterD-Seriall/0/0] quit
Step 5 Verify the configuration.
Issue 5.3 (30 March 2009) Nortel Networks Inc. 8-63
