MAXQ7667 User’s Guide
4.1.27 Data Pointer 1 Register (DP[1])
Register Description: Data Pointer 1 Register
Register Name: DP[1]
Register Address: Module 0Fh, Index 07h
Bits 15 to 0: Data Pointer 1 Register Bits 15:0 (DP[1][15:0]). This register is used as a pointer to access data memory. DP[1] can
be automatically incremented or decremented following each read operation or can be automatically incremented or decremented
before each write operation.
Bit # 15 14 13 12 11 10 9 8
Name DP[1]15 DP[1]14 DP[1]13 DP[1]12 DP[1]11 DP[1]11 DP[1]9 DP[1]8
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Name DP[1]7 DP[1]6 DP[1]5 DP[1]4 DP[1]3 DP[1]2 DP[1]1 DP[1]0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
r = read, w = write
Note: This register is cleared to 0000h on all forms of reset.
