6-9 ___________________________________________________________________________________________________________
MAXQ7667 User’s Guide
Bits 2 and 1: Capture/Compare Function Select Bits (CCF1 and CCF0). These bits, in conjunction with the C/T2 bit, select the basic
operating mode of the Type 2 timer. In the dual 8-bit mode of operation (T2MD = 1), the T2Lx timer only operates in compare mode.
Bit 0: Counter/Timer Select (C/T2). This bit enables/disables the edge counter mode of operation for the 16-bit counter (T2Vx) or the
8-bit counter (T2Hx) when the dual 8-bit mode of operation is enabled (T2MD = 1). The edge for counting (rising/falling/both) is defined
by the CCF[1:0] bits.
0 = timer mode
1 = counter mode
6.3.2 Type 2 Timer/Counter Control Register A (T2CNAx)
Register Description: Type 2 Timer/Counter Control Register A
Register Name T2CNAx (x = 0, 1, 2)
Register Address:
T2CNA0: Module 02h, Index 00h
T2CNA1: Module 02h, Index 04h
T2CNA2: Module 03h, Index 00h
Bits 15 to 8: Reserved. Read 0, write ignored.
Bit 7: Enable Type 2 Timer Interrupts (ET2). This bit serves as the local enable for the Type 2 timer interrupt sources that fall under
the TF2 and TCC2 interrupt flags.
Bit # 15 14 13 12 11 10 9 8
Name — — — — — — — —
Reset 0 0 0 0 0 0 0 0
Access r r r r r r r r
Bit # 7 6 5 4 3 2 1 0
Name ET2 T2OE0 T2POL0 TR2L TR2 CPRL2 SS2 G2EN
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
r = read, w = write
CCF1 CCF0 EDGE(s) C/T2 = 0 (TIMER MODE) C/T2 = 1 (COUNTER MODE)
0 0 None Compare Mode Disabled
0 1 Rising Capture/Reload Counter
1 0 Falling Capture/Reload Counter
1 1 Rising and Falling Capture/Reload Counter
