MAXQ7667 User’s Guide
6.5 Type 2 Reload Register
6.5.1 Type 2 Timer/Counter Reload Register (T2Rx)
Register Description: Type 2 Timer/Counter Reload Register
Register Name: T2Rx (x = 0, 1, 2)
Register Address:
T2R0: Module 02h, Index 0Ah
T2R1: Module 02h, Index 0Eh
T2R2: Module 03h, Index 0Ah
Bits 15 to 0: Type 2 Timer/Counter Reload Register (T2Rx[15:0]). This 16-bit register holds the reload value for the timer. When oper-
ating in 16-bit mode (T2MD = 0), the full 16 bits are read/write accessible. If the dual 8-bit mode of operation is selected, the upper
byte of T2Rx is inaccessible. T2Rx reads while in the dual 8-bit mode return 00h as the high byte and writes to the upper byte of T2Rx
are blocked. A separate T2RHx register is provided to facilitate high-byte access for the dual 8-bit mode.
Note: For convenience, the lower byte of T2Rx (T2Rx[7:0]) is referred to as T2RLx. Unlike T2RHx, there is no separate T2RLx register
and the low byte is always accessed through T2Rx.
Bit # 15 14 13 12 11 10 9 8
Name T2Rx15 T2Rx14 T2Rx13 T2Rx12 T2Rx11 T2Rx10 T2Rx9 T2Rx8
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Name T2Rx7 T2Rx6 T2Rx5 T2Rx4 T2Rx3 T2Rx2 T2Rx1 T2Rx0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
r = read, w = write
