3-16

MAXQ7667 User’s Guide

3.10 Accessing Data Memory

Data memory is accessed through the data pointer registers DP[0] and DP[1] or the Frame Pointer BP[OFFS]. Once one of these reg-

isters is set to a location in data memory, that location can be read or written as follows, using the mnemonic @DP[0], @DP[1] or

@BP[OFFS] as a source or destination.

move DP[0], #0000h

; set pointer to location 0000h

move A[0], @DP[0]

; read from data memory

move @DP[0], #55h

; write to data memory

Either of the data pointers may be post-incremented or post-decremented following any read or may be preincremented or predecre-

mented before any write access by using the following syntax.

move A[0], @DP[0]++

; increment DP[0] after read

move @++DP[0], A[1]

; increment DP[0] before write

move A[5], @DP[1]--

; decrement DP[1] after read

move @--DP[1], #00h

; decrement DP[1] before write

The Frame Pointer (BP[OFFS]) is actually composed of a base pointer (BP) and an offset from the base pointer (OFFS). For the frame

pointer, the offset register (OFFS) is the target of any increment or decrement operation. The base pointer (BP) is unaffected by incre-

ment and decrement operations on the Frame Pointer. Similar to DP[n], the OFFS register may be preincremented/decremented when

writing to data memory and may be postincremented/decremented when reading from data memory.

move A[0], @BP[OFFS--]

; decrement OFFS after read

move @BP[++OFFS], A[1]

; increment OFFS before write

All three data pointers support both byte and word access to data memory. Each data pointer has its own word/byte select (WBSn)

special-function register bit to control the access mode associated with the data pointer. These three register bits (WBS2, which con-

trols BP[OFFS] access; WBS1, which controls DP[1] access; and WBS0, which controls DP[0] access) reside in the Data Pointer

Control (DPC) register. When a given WBSn control bit is configured to 1, the associated pointer is operated in the word access mode.

When the WBSn bit is configured to 0, the pointer is operated in the byte access mode. Word access mode allows addressing of

64KWords of memory while byte access mode allows addressing of 64KB of memory.

Each data pointer (DP[n]) and Frame Pointer base (BP) register is actually implemented internally as a 17-bit register (e.g., 16:0). The Frame

Pointer offset register (OFFS) is implemented internally as a 9-bit register (e.g., 8:0). The WBSn bit for the respective pointer controls whether

the highest 16 bits (16:1) of the pointer are in use, as is the case for word mode (WBSn = 1) or whether the lowest 16 bits (15:0) are in use,

as will be the case for byte mode (WBSn = 0). The WBS2 bit also controls whether the high 8 bits (8:1) of the offset register are in use

(WBS2 = 1) or the low 8 bits (7:0) are used (WBS2 = 0). All data pointer register reads, writes, autoincrement/decrement operations occur

with respect to the current WBSn selection. Data pointer increment and decrement operations only affect those bits specific to the current

word or byte addressing mode (e.g., incrementing a byte mode data pointer from FFFFh does not carry into the internal high order bit that

is utilized only for word mode data pointer access). Switching from byte to word access mode or vice versa does not alter the data pointer

contents. Therefore, it is important to maintain the consistency of data pointer address value within the given access mode.

move DPC, #0

; DP[0] in byte mode

move DP[0], #2345h ; DP[0]=2345h (byte mode)

; internal bits 15:0 loaded

move DPC, #4

; DP[0] in word mode

move DP[0], #2345h

; DP[0]=2345h (word mode)

; internal bits 16:1 loaded

move DPC, #0

; DP[0] in byte mode

move GR, DP[0]

; GR = 468Bh (looking at bits 15:0)

The three pointers share a single read/write port on the data memory and thus, the user must knowingly activate a desired pointer

before using it for data memory read operations. This can be done explicitly using the data pointer select bits (SDPS[1:0]; DPC.[1:0]),

or implicitly by writing to the DP[n], BP, or OFFS registers as shown below. Any indirect memory write operation using a data pointer

will set the SDPS bits, thus activating the write pointer as the active source pointer.

move DPC, #2

; (explicit) selection of FP as the pointer

move DP[1], DP[1]

; (implicit) selection of DP[1]; set SDPS1:0=01b

move OFFS, src

; (implicit) selection of FP; set SDPS1=1

move @DP[0], src

; (implicit) selection of DP[0]; set SDPS1:0=00b
