12-9 __________________________________________________________________________________________________________
MAXQ7667 User’s Guide
12.2.8 System Control Register (SC)
Register Description: System Control Register
Register Name: SC
Register Address: Module 08h, Index 08h
Bit 7: Test Access (JTAG) Port Enable (TAP). This bit controls whether the TAP special function pins are enabled. The TAP defaults
to being enabled. See Section 11 for more information on this bit.
0 = JTAG/TAP functions are disabled and P0.0–P0.3 can be used as general-purpose I/O pins
1 = TAP special function pins P0.0–P0.3 are enabled to act as JTAG inputs and outputs
Bits 6 and 0: Reserved
Bits 5 and 4: Code Data Access Bits 1 and 0 (CDA[1:0]). See Section 2 for more information on these bits.
Bit 3: Upper Program Access (UPA). See Section 2 for more information on this bit.
Bit 2: ROM Operation Done (ROD). This bit is used to signify completion of a ROM operation sequence. The utility ROM signals that
it has completed a requested task by setting the ROD (ROM operation done) bit of the SC register to logic 1. The ROD bit is reset by
the debug engine when it recognizes the done condition. Setting the ROD bit to 1 when the SPE bit is also set causes the system to
reset.
Bit 1: Password Lock (PWL). This bit defaults to 1 on a power-on reset. When this bit is 1, it requires a 32-byte password to be
matched with the password in the program space before allowing access to the password protected in-circuit debug or bootstrap
loader ROM routines. Clearing this bit to 0 disables the password protection for these ROM routines. See Section 13 for more infor-
mation on this bit.
Bit # 7 6 5 4 3 2 1 0
Name TAP — CDA1 CDA0 UPA ROD PWL —
Reset 0 0 0 0 0 0 1 0
Access rw r rw rw rw rw rw r
r = read, w = write
*This register defaults to 80h on all forms of reset except after power-on reset. After power-on reset, the PWL bit is also set and this register defaults to 82h.
