4.1.14 Interrupt Vector Register (IV)
Register Description:
Interrupt Vector Register
Register Name:
IV
Register Address:
Module 0Dh, Index 02h
Bits 15 to 0: Interrupt Vector Register Bits 15:0 (IV[15:0]). This register contains the address of the interrupt service routine. The
interrupt handler will generate a CALL to this address whenever an interrupt is acknowledged.
4.1.15 Loop Counter 0 Register (LC[0])
Register Description:
Loop Counter 0 Register
Register Name:
LC[0]
Register Address:
Module 0Dh, Index 06h
Bits 15 to 0: Loop Counter 0 Register Bits 15:0 (LC[0][15:0]). This register is used as the loop counter for the DJNZ LC[0], src oper-
ation. This operation decrements LC[0] by one and then jumps to the address specified in the instruction by src.
Bit #
15
14
13
12
11
10
9
8
Name
IV15
IV14
IV13
IV12
IV11
IV10
IV9
IV8
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
Bit #
7
6
5
4
3
2
1
0
Name
IV7
IV6
IV5
IV4
IV3
IV2
IV1
IV0
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
r = read, w = write
Note: This register is cleared to 0000h on all forms of reset.
Bit #
15
14
13
12
11
10
9
8
Name
LC[0]15
LC[0]14
LC[0]13
LC[0]12
LC[0]11
LC[0]10
LC[0]9
LC[0]8
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
Bit #
7
6
5
4
3
2
1
0
Name
LC[0]7
LC[0]6
LC[0]5
LC[0]4
LC[0]3
LC[0]2
LC[0]1
LC[0]0
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
r = read, w = write
Note: This register is cleared to 0000h on all forms of reset.
