14-8
MAXQ7667 User’s Guide
14.3.4 SAR ADC Output Data Register (SARD)
Register Description:
SAR ADC Output Data Register
Register Name:
SARD
Register Address:
Module 05h, Index 09h
Bits 15 to 12: Reserved. Read returns 0.
Bits 11 to 0: SAR ADC Output Data 11:0 (SARD[11:0])
14.3.5 Oscillator Control Register (OSCC)
Register Description:
Oscillator Control Register
Register Name:
OSCC
Register Address:
Module 05h, Index 0Bh
Bits 15 to 4: Reserved. Read returns 0.
Bits 3 and 2: SAR ADC Clock Divider (SARCD[1:0]). Determines the SAR ADC clock frequency, which is divided down from the clock
source selected by the XTRC (CKCN.7) bit.
00 divides by 2
01 divides by 4
Bit #
15
14
13
12
11
10
9
8
Name
—
—
—
—
SARD11
SARD10
SARD9
SARD8
Reset
0
0
0
0
0
0
0
0
Access
r
r
r
r
r
r
r
r
Bit #
7
6
5
4
3
2
1
0
Name
SARD7
SARD6
SARD5
SARD4
SARD3
SARD2
SARD1
SARD0
Reset
0
0
0
0
0
0
0
0
Access
r
r
r
r
r
r
r
r
r = read
Note: SARD is cleared to 0000h on all forms of reset.
Bit #
15
14
13
12
11
10
9
8
Name
—
—
—
—
—
—
—
—
Reset
0
0
0
0
0
0
0
0
Access
r
r
r
r
r
r
r
r
Bit #
7
6
5
4
3
2
1
0
Name
—
—
—
—
SARCD1
SARCD0
XTE
RCE
Reset
0
0
0
0
0
0
0
0
Access
r
r
r
r
r
r
r
r
r = read (Note that some clock control bits may have locking mechanisms for write.)
Note: OSCC is cleared to 0000h on power-on reset.
