MAXQ7667 User’s Guide
6.2 Type 2 Timer/Counter Peripheral Registers
Table 6-2. Type 2 Timer/Counter Register Map
REGISTER
MODULE
NUMBER
INDEX FUNCTION
T2CFG0 02h 10h
Timer/Counter 0 (Type 2) Configuration Register. Controls counter/timer select, capture/compare function
select, 8-/16-bit mode select, and clock divide modes.
T2CNA0 02h 00h Timer/Counter 0 (Type 2) Control Register A. I/O settings, run enables, polarity modes.
T2CNB0 02h 08h Timer/Counter 0 (Type 2) Control Register B. Contains capture, compare, overflow flags.
T2V0 02h 09h Timer/Counter 0 (Type 2) Value Register
T2H0 02h 01h Timer/Counter 0 (Type 2) Value MSB Register. Provides access to high byte of T2V register.
T2R0 02h 0Ah Timer/Counter 0 (Type 2) Reload Register
T2RH0 02h 02h Timer/Counter 0 (Type 2) Reload MSB Register. Provides access to high byte of T2R register.
T2C0 02h 0Bh Timer/Counter 0 (Type 2) Capture/Compare Register
T2CH0 02h 03h Timer/Counter 0 (Type 2) Capture/Compare MSB Register. Access to high byte of T2C.
T2CFG1 02h 11h
Timer/Counter 1 (Type 2) Configuration Register. Controls counter/timer select, capture/compare function
select, 8-/16-bit mode select, and clock divide modes.
T2CNA1 02h 04h Timer/Counter 1 (Type 2) Control Register A. I/O settings, run enables, polarity modes.
T2CNB1 02h 0Ch Timer/Counter 1 (Type 2) Control Register B. Contains capture, compare, overflow flags.
T2V1 02h 0Dh Timer/Counter 1 (Type 2) Value Register
T2H1 02h 05h Timer/Counter 1 (Type 2) Value MSB Register. Provides access to high byte of T2V register.
T2R1 02h 0Eh Timer/Counter 1 (Type 2) Reload Register
T2RH1 02h 06h Timer/Counter 1 (Type 2) Reload MSB Register. Provides access to high byte of T2R register.
T2C1 02h 0Fh Timer/Counter 1 (Type 2) Capture/Compare Register
T2CH1 02h 07h Timer/Counter 1 (Type 2) Capture/Compare MSB Register. Access to high byte of T2C.
T2CFG2 03h 10h
Timer/Counter 2 (Type 2) Configuration Register. Controls counter/timer select, capture/compare function
select, 8-bit/16-bit mode select, and clock divide modes
T2CNA2 03h 00h Timer/Counter 2 (Type 2) Control Register A. I/O settings, run enables, polarity modes
T2CNB2 03h 08h Timer/Counter 2 (Type 2) Control Register B. Contains capture, compare, overflow flags.
T2V2 03h 09h Timer/Counter 2 (Type 2) Value Register
T2H2 03h 01h Timer/Counter 2 (Type 2) Value MSB Register. Provides access to high byte of T2V register.
T2R2 03h 0Ah Timer/Counter 2 (Type 2) Reload Register
T2RH2 03h 02h Timer/Counter 2 (Type 2) Reload MSB Register. Provides access to high byte of T2R register.
T2C2 03h 0Bh Timer/Counter 2 (Type 2) Capture/Compare Register
T2CH2 03h 03h Timer/Counter 2 (Type 2) Capture/Compare MSB Register. Access to high byte of T2C.
