8.3.17 Timer Register (UART) (TMR)
Register Description:
Timer Register
Register Name:
TMR
Register Address:
Module 03h, Index 1Ah
Bits 15 to 0: Timer Register 15:0 (TMR[15:0]). This register is written by the host during system initialization to indicate the number
of system clock cycles in a 50µs period.
8.4 MAXQ7667 LIN
8.4.1 MAXQ7667 LIN Features
The MAXQ7667 LIN provides the following features:
•
Supports LIN 1.3, LIN 2.0, and SAE J2602
•
Automatic baud-rate detection and LIN frame synchronization
•
Automatic calculation of standard (LIN 1.3) and enhanced (LIN 2.0) checksums
•
Frame lengths up to 64 bytes
•
Support for LIN power management modes
•
8-byte transmit and receive FIFOs to reduce processor intervention
•
Configurable digital filter for receiver
8-17
__________________________________________________________________________________________________________
MAXQ7667 User’s Guide
r = read, w = write
Note: TMR is cleared to 0000h on all forms of reset.
Bit #
15
14
13
12
11
10
9
8
Name
TMR15
TMR14
TMR13
TMR12
TMR11
TMR10
TMR9
TMR8
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
Bit #
7
6
5
4
3
2
1
0
Name
TMR7
TMR6
TMR5
TMR4
TMR3
TMR2
TMR1
TMR0
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
