4-7 ___________________________________________________________________________________________________________
MAXQ7667 User’s Guide
Bits 2 to 0: Accumulator Pointer Autoincrement/Decrement Modulus (MOD[2:0]). If these bits are set to a nonzero value, the accu-
mulator pointer (AP[3:0]) will be automatically incremented or decremented following each arithmetic or logical operation. The mode
for the autoincrement/decrement is determined as follows:
4.1.3 Processor Status Flags Register (PSF)
Register Description: Processor Status Flags Register
Register Name: PSF
Register Address: Module 08h, Index 04h
Bit 7: Zero Flag (Z). The value of this bit flag equals 1 whenever the active accumulator is equal to zero, and it equals 0 otherwise.
Bit 6: Sign Flag (S). This bit flag mirrors the current value of the high bit of the active accumulator (Acc.15).
Bit 5: Reserved. Read 0, write ignored.
Bits 4 and 3: General-Purpose Software Flag 1 and 0 (GPF[1:0]). These general-purpose register bits are provided for user software
control.
Bit 2: Overflow Flag (OV). This flag is set to 1 if there is a carry out of bit 14 but not out of bit 15, or a carry out of bit 15 but not out
of bit 14 from the last arithmetic operation, otherwise, the OV flag remains as 0. OV indicates a negative number resulted as the sum
of two positive operands, or a positive sum resulted from two negative operands.
Bit 1: Carry Flag (C). This bit flag is set to 1 whenever an add or subtract operation (ADD, ADDC, SUB, SUBB) returns a carry or bor-
row. This bit flag is cleared to 0 whenever an add or subtract operation does not return a carry or borrow. Many other instructions poten-
tially affect the carry bit. See Section 19: Instruction Set Summary for details.
Bit 0: Equals Flag (E). This bit flag is set to 1 whenever a compare operation (CMP) returns an equal result. If a CMP operation returns
not equal, this bit is cleared.
MOD[2:0] AUTOINCREMENT/DECREMENT MODE
000 No autoincrement/decrement (default).
001 Increment/decrement AP[0] modulo 2.
010 Increment/decrement AP[1:0] modulo 4.
011 Increment/decrement AP[2:0] modulo 8.
100 Increment/decrement AP modulo 16.
101 to 111 Reserved (modulo 16 when set).
Bit # 7 6 5 4 3 2 1 0
Name Z S — GPF1 GPF0 OV C E
Reset 1 0 0 0 0 0 0 0
Access r r r rw rw r rw rw
r = read, w = write
Note: This register is cleared to 80h on all forms of reset.
