__________________________________________________________________________________________________________ 6-16
MAXQ7667 User’s Guide
6.6 Type 2 Capture/Compare Registers
6.6.1 Type 2 Timer/Counter Capture/Compare Register (T2Cx)
Register Description: Type 2 Timer/Counter Capture/Compare Register
Register Name: T2Cx (x = 0, 1, 2)
Register Address:
T2C0: Module 02h, Index 0Bh
T2C1: Module 02h, Index 0Fh
T2C2: Module 03h, Index 0Bh
Bits 15 to 0: Type 2 Timer/Counter Capture/Compare Register (T2Cx[15:0]). This 16-bit register holds the compare value when
operating in compare mode and gets the capture value when operating in capture mode. When operating in 16-bit mode (T2MD = 0),
the full 16 bits are read/write accessible. If the dual 8-bit mode of operation is selected, the upper byte of T2Cx is inaccessible. T2Cx
reads while in the dual 8-bit mode return 00h as the high byte and writes to the upper byte of T2Cx are blocked. A separate T2CHx
register is provided to facilitate high-byte access.
Note: For convenience, the lower byte of T2Cx (T2Cx[7:0]) is referred to as T2CLx. Unlike T2CHx, there is no separate T2CLx register
and the low byte is always accessed through T2Cx.
Bit # 15 14 13 12 11 10 9 8
Name T2Cx15 T2Cx14 T2Cx13 T2Cx12 T2Cx11 T2Cx10 T2Cx9 T2Cx8
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Name T2Cx7 T2Cx6 T2Cx5 T2Cx4 T2Cx3 T2Cx2 T2Cx1 T2Cx0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
r = read, w = write
