MAXQ7667 User’s Guide
6.4 Type 2 Counter Registers
6.4.1 Type 2 Timer/Counter Value Register (T2Vx)
Register Description: Type 2 Timer/Counter Value Register
Register Name: T2Vx (x = 0, 1, 2)
Register Address:
T2V0: Module 02h, Index 09h
T2V1: Module 02h, Index 0Dh
T2V2: Module 03h, Index 09h
Bits 15 to 0: Type 2 Timer/Counter Value Register (T2Vx[15:0]). The T2Vx register is a 16-bit register that holds the current timer value.
When operating in 16-bit mode (T2MD = 0), the full 16 bits are read/write accessible. If the dual 8-bit mode of operation (T2MD = 1) is
selected, the upper byte of T2Vx is inaccessible. T2Vx reads while in the dual 8-bit mode return 00h as the high byte and writes to the
upper byte of T2Vx are blocked. A separate T2Hx register is provided to facilitate high-byte access for dual 8-bit mode.
Note: For convenience, the lower byte of T2Vx (T2Vx[7:0]) is referred to as T2Lx. Unlike T2Hx, there is no separate T2Lx register and
the low byte is always accessed through T2Vx.
Bit # 15 14 13 12 11 10 9 8
Name T2Vx15 T2Vx14 T2Vx13 T2Vx12 T2Vx11 T2Vx10 T2Vx9 T2Vx8
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
Bit # 7 6 5 4 3 2 1 0
Name T2Vx7 T2Vx6 T2Vx5 T2Vx4 T2Vx3 T2Vx2 T2Vx1 T2Vx0
Reset 0 0 0 0 0 0 0 0
Access rw rw rw rw rw rw rw rw
r = read, w = write
