MAXQ7667 User’s Guide

Bit 6: Type 2 Timer Output Enable 0 (T2OE0). This register bit enables the timer output function for the external T2P pin. The follow-
ing table shows the timer output possibilities for the T2P, T2PB pins. (T2OE1 bit is in the T2CNBx register.)

Bit 5: Type 2 Timer Polarity Select 0 (T2POL0). When the timer output function has been enabled (T2OE0 = 1), the polarity select bit
defines the starting logic level for the T2Px output waveform. When T2POL0 = 0, the starting state for the T2Px output is logic low. When

T2POL0 = 1, the starting state for the T2Px output is logic high. The T2POL0 bit can be modified at any time, but takes effect on the

external pin when T2OE0 is changed from 0 to 1. When the Type 2 timer pin is being used as an input (T2OE0 = 0), the polarity select

bit defines which logic level can be used to gate the timer input clock (when CCF[1:0] = 11b). When CCF[1:0] = 11b, T2POL0 defines

which edge can start/stop a single-shot capture and which edge reload can be skipped (if CPRL2 = 1 and G2EN = 1).

Bit 4: Type 2 Timer Low Run Enable (TR2L). This bit start/stops the low 8-bit timer (T2Lx) when dual 8-bit mode (T2MD = 1) is in
effect. This bit has no effect when T2MD = 0.

0 = timer low stopped

1 = timer low run

Bit 3: Type 2 Timer Run Enable (TR2). This bit starts/stops timer 2. In the dual 8-bit mode of operation, this bit applies only to the
T2Hx timer/counter. Otherwise, the bit applies to the full 16-bit T2Vx timer/counter. When the timer is stopped (TR2 = 0), the timer reg-

isters hold their count. The single-shot bit (SS2) can override and/or delay the effect of the TR2 bit.

0 = timer stopped

1 = timer run

Bit 2: Capture and Reload Enable (CPRL2). This bit enables a reload (in addition to a capture) on the edge specified by CCF1:CCF0
when operating in capture/reload mode (C/T2 = 0). If both edges are defined for capture/reload (CCF[1:0] = 11b), enabling the gating

control (G2EN = 1) allows the T2POL0 bit to be used to prevent a reload on one of the edges if T2POL0 is 0, no reload on the falling

edge; or, if T2POL0 is 1, no reload on the rising edge.

0 = capture on edge(s) specified by CCF[1:0] bits

1 = capture and reload on edge(s) specified by CCF[1:0] bits

Bit 1: Single-Shot (SS2). This bit is used to automatically override or delay the effect of the TR2 bit setting. The single-shot bit is only
useful in the timer mode of operation (C/T2 = 0) and should not be set to 1 when the counter mode of operation is enabled (C/T2 = 1).

Compare Mode: If SS2 is written to 1 while in compare mode, one cycle of the defined waveform (reload to overflow) is output to
the T2Px, T2PBx pins as prescribed by T2POL[1:0] and T2OE[1:0] controls. The only time that this does not immediately occur is

when a gating condition is also defined. If a gating condition is defined, the single-shot cycle cannot occur until the gating con-

dition is removed. If the specified nongated level is already in effect, the single-shot period starts. The gated single-shot output is

not supported in dual 8-bit mode.

Capture Mode: If SS2 is written to 1 while in capture mode, the timer is halted and the single-shot capture cycle does not begin
until 1) the edge specified by CCF[1:0] is detected, or 2) the defined gating condition is removed. Once running, the timer con-

tinues running (as allowed by the gate condition) until the defined capture single-shot edge is detected. In this way, the SS2 bit

can be used to delay the running of a timer until an edge is detected (setting both SS2 and TR2 = 1) or override the TR2 = 0 bit

setting for one capture cycle (setting only SS2 = 1). When both edges are defined for capture (CCF[1:0] = 11b), the T2POL0 bit

serves to define the single-shot start/end edge: falling edge if T2POL0 = 1, rising edge if T2POL0 = 0. No interrupt flag is set when

the starting edge for the single-shot capture cycle is detected. The single-shot capture cycle always ends when the next single-

shot edge is detected. The start/end edge is defined by T2POL0. This bit is intended to automate pulse-width measurement (low

or high) and duty cycle/period measurement.

T2OE[1:0]

T2MD

T2P

T2PB

Port latch data

16-bit PWM output

Port latch data

16-bit PWM output

8-bit PWM output (T2Hx)

Port latch data

8-bit PWM output (T2Lx)

8-bit PWM output (T2Hx)

8-bit PWM output (T2Lx)
