MAXQ7667 User’s Guide
x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF
0x PO0 PO1 00 00 EIF0 EIF1 00 00 00 00 00 00
1x PI0 PI1 00 00 EIE0 EIE1 00 00 00 00 00 00
2x PD0 PD1 00 00 EIES0 EIES1 00 00 00 00 00 00
3x PS0 PS1 00 00 PR0 PR1 00 00 00 00 00 00
4x MCNT MA MB MC2 MC1 MC0 00 00 SPICN
5x SPICF SPICK FCNTL* FDATA* MCR1 MC0R SCNT STIM
6x SALM FPCTL 00 00 00 00 BIASTRM* BGTRM* MONTRM* RCTRM
7x SP0TRM* SP1TRM* SARLTRM* SAROTRM* ID0 ID1 ID2* ID3*
8x T2CNA0 T2H0 T2RH0 T2CH0 T2CNA1 T2H1 T2RH1 T2CH1
9x T2CNB0 T2V0 T2R0 T2C0 T2CNB1 T2V1 T2R1 T2C1
Ax T2CFG0 T2CFG1 00 00 00 00 00 00 00 00 00 00 00 00
Bx ICDT0 ICDT1 00 ICDC 00 ICDF 00 ICDB ICDA ICDD TM*
Cx T2CNA2 T2H2 T2RH2 T2CH2 00 00 CNT1 SCON 00 00
Dx T2CNB2 T2V2 T2R2 T2C2 FSTAT ERRR CHKSUM ISVEC
Ex T2CFG2 STA0 SMD FCON CNT0 CNT2 IDFB SADDR
Fx SADEN BT TMR 00 00 00 00 00 00 00 00 00 00
10x 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
11x 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
12x 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
13x 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
14x BPH BTRN SARC RCVC PLLF AIE CMPC CMPT
15x 00 00 SARD LPFC OSCC BPFI BPFO LPFD LPFF
16x APE ATST FGAIN B1COEF B2COEF B3COEF A2A A2B
17x 00 00 A2D 00 00 A3A A3B 00 00 A3D 00 00
18x AP APC PSF IC IMR SC IIR CKCN WDCN 00 A[0] A[1] A[2]
19x A[3] A[4] A[5] A[6] A[7] A[8] A[9] A[10]
1Ax A[11] A[12] A[13] A[14] A[15] IP SP+1 IV
1Bx LC[0] LC[1] OFFS DPC GR BP DP[0] DP[1]
Table 12-3. Output from Read Register Map Command
*Reserved for factory use.
