MAXQ7667 User’s Guide
18.4 ROM Example 2: Calling A MAXQ7667 Utility ROM Function Indirectly
The second example shows the indirect addressing method (lookup table) for calling MAXQ7667 utility functions. We use the same
function ( UROM_MoveDP1Inc) to read our static string, but this time we must figure out the address we want dynamically. Note the
inserted code where we before had a direct call to the function. Also note that the function index of moveDP1inc is 8.
Text:
DB “Hello World!”,0 ; Define a string in code space.
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
;; Function: PrintText
;; Description: Prints the string stored at the “Text” label.
;; Returns: N/A
;; Destroys: ACC, DP[1], DP[0], and GR.
;; Notes: This function assumes that DP[0] is set to word mode, and
;; DP[1] is in byte mode.
;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;;
PrintText:
move DP[1], #Text ; Point to the string to display.
move ACC, DP[1] ; “Text” is a word address and we need a
sla ; byte address, so shift left 1 bit.
or #08000h ; Code space is mapped to 8000h when running
move DP[1], ACC ; from the ROM, so the address must be masked.
PrintText_Loop:
;
; Fetch the byte from code space.
;
move DP[0], #0800Dh ; This is where the address of the table is stored.
move ACC, @DP[0] ; Get the location of the function table.
add #7 ; Add the index to the moveDP1inc function.
move DP[0], ACC ; Point to where the address of moveDP1 is stored.
move ACC, @DP[0] ; Retrieve the address of the function.
call ACC ; Execute the function.
move ACC, GR
jump Z, PrintText_Done ; Reached the null terminator.
call PrintChar ; Call a routine to output the char in ACC
jump PrintText_Loop ; Process the next byte.
PrintText_Done:
ret
Refer to Application Note 4008: Calling Utility ROM Functions with IAR’s Embedded Workbench for MAXQ to see the C language imple-
mentation of the UROM functions.
