4-11
__________________________________________________________________________________________________________
MAXQ7667 User’s Guide
4.1.9 Watchdog Timer Control Register (WDCN)
The 8-bit WDCN register is part of the system register group and used to provide system control. It controls the watchdog timeout peri-
od and interrupt or reset generation on watchdog timeout. The watchdog timer is clocked by the internal RC oscillator. See Section 15
for a description of this register.
Register Description:
Watchdog Timer Control Register
Register Name:
WDCN
Register Address:
Module 08h, Index 0Fh
4.1.10 Accumulator n Register (A[n])
Register Description:
Accumulator n Register
Register Name:
A[n]
Register Address:
Module 09h, Index 0nh
Bits 15 to 0: Accumulator n Register Bits 15:0 (A[n][15:0]). This register acts as the accumulator for all ALU arithmetic and logical
operations when selected by the accumulator pointer (AP). It can also be used as a general-purpose working register.
Bit #
7
6
5
4
3
2
1
0
Name
POR
EWDI
WD1
WD0
WDIF
WTRF
EWT
RWT
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
r = read, w = write
Note: Bits 5, 4, 3, and 0 are cleared to 0 on all forms of reset; for others, see the individual bit descriptions.
Bit #
15
14
13
12
11
10
9
8
Name
A[n]15
A[n]14
A[n]13
A[n]12
A[n]11
A[n]10
A[n]9
A[n]8
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
Bit #
7
6
5
4
3
2
1
0
Name
A[n]7
A[n]6
A[n]5
A[n]4
A[n]3
A[n]2
A[n]1
A[n]0
Reset
0
0
0
0
0
0
0
0
Access
rw
rw
rw
rw
rw
rw
rw
rw
r = read, w = write
Note: This register is cleared to 0000h on all forms of reset.
