AT-S70 Management Software User’s Guide
99
Displaying Line Card Information
To view the MAC addresses and serial numbers of the line cards, perform
the following procedure:
1. From the Main Menu, select Administration.
The Administration Menu is displayed, as shown in Figure 6 on page
38.
2. From the Administration Menu, select Diagnostics.
The Diagnostic Menu is displayed, as shown in Figure 38 on page 95.
3. From the Diagnostics Menu, select Line Card Information.
The Line Card Module Information menu is displayed. The example in
Figure 41 shows an AT-CV5000 chassis.
Figure 41. Line Card Module Information Menu
The Line Card Module Information window contains the following
information:
Line Card Module Information
Converteon
Module MAC Address Serial Number
1: AT-CV5M01 000C469A214B 7
2: AT-CM202 323032055148 SN # 32
3: AT-CM202 437032055272 SN # 43
4: AT-CM202 983032055331 4#21
5:(Not Inserted) -- --
6: AT-CM212A/1 503032055515 6#38
7: AT-CM212A/1 000C469A21E6 142
8: AT-CM212B/1 210C469A21DF 155
9: AT-CM212B/1 000C469A21DF 135
10:(Not Inserted) -- --
11: AT-CV1KSS 078C435A21AA 321
12: AT-CV1KSS 000C469A21DF 4#36
13: AT-CV1KSS 017C469A07ST 243
14: AT-CV1KSS 850A869369QT 027
15: AT-CM70S 000CDFDF13FF 2323
16:(Not Inserted) -- --
17: AT-CM202 043032874335 SN # 53
18: AT-CM202 323032055702 SN # 67
Hit any key to continue ...
