AT-S70 Management Software User’s Guide
93
Starting and
Stopping the
Activity Monitor
To start or stop the activity log, perform the following procedure:
1. From the Main Menu, select Administration.
The Administration Menu is displayed, as shown in Figure 6 on page
38.
2. From the Administration Menu, select Start Activity Monitor to start
the activity monitor or Stop Activity Monitor to stop the activity
monitor. The default is Stop Activity Monitor.
Displaying the
Activity Log
To view the activity log, perform the following procedure:
1. From the Main Menu, select Administration.
The Administration Menu is displayed, as shown in Figure 6 on page
38.
2. From the Administration Menu, select Activity Monitor.
An example of the Activity Monitor display is shown in Figure 37.
Figure 37. Activity Monitor Display Example
The activity monitor continues to display system activities until you
press Return.
3. Press or select the “Return to ...” option at the bottom of the
menu to return to the previous menu.
Converteon
Activity Monitor
(hit Return to resume the previous menu)
00/00/00 00:00:23 Module #5 has been removed!
00/00/00 00:00:25 Module #5 has been Installed!
00/00/00 00:00:30 Module #10 has been removed!
00/00/00 00:00:33 Module #10 has been Installed!
00/00/00 00:00:34 Power Tray A has been Installed!
00/00/00 00:00:34 Power Tray B has been removed!
