AT-S70 Management Software User’s Guide
115
Configuring OAM Operations on a Port
To configure the OAM operations, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 46.
Note
The information displayed in this menu varies depending on the
chassis used. For illustration purposes, an AT-CV5000 chassis is
shown in Figure 46.
Figure 46. Module Status and Configuration Menu for an AT-CV5000
Chassis
2. Select the line card whose OAM operations you want to configure.
3. Press
Module Status and Configuration
Converteon
Module
Status
Link(A)
Link(B)
OpMode
1: AT-CV5M01
On
Online/100
2: AT-CM202
On
Online/100
Offline
OAM Visible
3: AT-CM202
On
Online/100
Offline
OAM Visible
4: AT-CM202
On
Online/100
Online/10
OAM Visible
5:(Not Inserted)
--
--
--
--
6: AT-CM212A/1
On
Online/100
Online/100
Link Test
7: AT-CM212A/1
On
Online/100
Offline
Link Test
8: AT-CM212B/1
On
Online/100
Online/100
SML
9: AT-CM212B/1
On
Online/100
Online/100
SML
10:(Not Inserted)
--
--
--
--
11: AT-CV1KSS
On
Online/1000
Online/1000
Link Test
12: AT-CV1KSS
On
Online/1000
Online/1000
Link Test
13: AT-CV1KSS
On
Online/1000
Offline
Link Test
14: AT-CV1KSS
On
Online/1000
Online/1000
Link Test
15: AT-CM70S
On
Online
Online
Link Test
16:(Not Inserted)
--
--
--
--
More ...
Return to Main Menu ...
