AT-S70 Management Software User’s Guide
43
The Terminal Configuration Menu is displayed, as shown in Figure 8.
Figure 8. Terminal Configuration Menu
3. From the Terminal Configuration Menu, select Data rate (baud rate).
The Terminal Data Rate Menu is displayed, as shown in Figure 9.
Figure 9. Terminal Data Rate Menu
4. From the Terminal Data Rate Menu, select the baud rate you want.
The possible baud rates are:
ˆ 115200 bps (default)
ˆ 57600 bps
ˆ 19200 bps
ˆ 9600 bps
ˆ 4800 bps
ˆ 2400 bps
5. From the Main Menu, select System Configuration.
The System Configuration Menu is displayed, as shown in Figure 3 on
page 29.
6. From the System Configuration Menu, select Save Configuration
File.
Terminal Configuration Menu
Converteon
Data Rate (baud rate) ...
Return to System Configuration Menu...
Terminal Data Rate Menu
Converteon
> 115200 bps
57600 bps
19200 bps
9600 bps
4800 bps
2400 bps
Return to Terminal Configuration Menu...
