AT-S70 Management Software User’s Guide
65
The Port Ingress Rate Menu, shown in Figure 19, or the Port Egress
Rate Menu, shown in Figure 20, is displayed.
Figure 19. Port Ingress Rate Menu
Ingress_Rate_Limit
The options for the ingress rate limit are: 128K, 256K, 512K, 1M, 2M, 4M,
and 8M. The default value is no ingress rate limit
(Ingress_Rate_Limit_No).
Figure 20. Port Egress Rate Menu
Egress_Rate_Limit
The options for the egress rate limit are: 128K, 256K, 512K, 1M, 2M,
4M, and 8M. The default value is no egress rate limit
(Egress_Rate_Limit_No)
8. From the Main Menu, select System Configuration.
Port Ingress Rate Menu
Converteon
> Ingress_Rate_Limit_No
Ingress_Rate_Limit_128K
Ingress_Rate_Limit_256K
Ingress_Rate_Limit_512K
Ingress_Rate_Limit_1M
Ingress_Rate_Limit_2M
Ingress_Rate_Limit_4M
Ingress_Rate_Limit_8M
Return to Port Configuration Menu ...
Port Egress Rate Menu
Converteon
> Egress_Rate_Limit_No
Egress_Rate_Limit_128K
Egress_Rate_Limit_256K
Egress_Rate_Limit_512K
Egress_Rate_Limit_1M
Egress_Rate_Limit_2M
Egress_Rate_Limit_4M
Egress_Rate_Limit_8M
Return to Port Configuration Menu ...
