AT-S70 Management Software User’s Guide
59
The Remote Module Status and Configuration Menu is displayed. The
examples in Figure 15 and in Figure 16 show an AT-CV5000 chassis.
Figure 15. Remote Module Status and Configuration Menu
2. In the Module Status and Configuration Menu, click More ... to display
the remainder of the modules and line cards in the chassis, as shown
in Figure 16.
Figure 16. Module Status and Configuration Menu - 2/2
The Remote Module Status and Configuration Menu displays the status of
the fiber optic connection between a local line card and a remote device,
as described below:
Remote Module Status and Configuration
Converteon
Remote Peer On Fiber Connection
Module Card Type Version Link Status (Port A)
1: AT-CV5M01 No Support No Support No Support
2: AT-CM202 -- -- --
3: AT-CM202 AT-CM212A/1 V.1.7.0 Online
4: AT-CM202 -- -- --
5:(Not Inserted) -- -- --
6: AT-CM212A/1 -- -- --
7: AT-CM212A/1 AT-CM202 V.1.7.0 Online
8: AT-CM212B/1 -- -- --
9: AT-CM212B/1 -- -- --
10:(Not Inserted) -- -- --
11: AT-CV1KSS No Support No Support No Support
12: AT-CV1KSS No Support No Support No Support
13: AT-CV1KSS No Support No Support No Support
14: AT-CV1KSS No Support No Support No Support
15: AT-CM70S -- -- -- --
16:(Not Inserted) -- -- -- --
More ...
Return to Main Menu ...
Module Status and Configuration
Converteon
Module Card Type Version Link Status (Port A)
17: AT-CM202 AT-CM212A/1 V.1.7.0 Online
18: AT-CM202 AT-CM212B/1 V.1.7.0 Online
More ...
Return to Main Menu ...
