AT-S70 Management Software User’s Guide
57
The Module Configuration Menu (an example of the AT-CM202 line
card is shown in Figure 13 on page 55) is displayed.
4. From the Module Configuration Menu, select Display DIP Switch
Setting.
The Display DIP Switch Setting menu is displayed, as shown in
Figure 14.
Figure 14. Display DIP Switch Setting
The possible DIP switch operating modes are:
ˆ ML (MissingLink™)
ˆ SML (Smart MissingLink)
ˆ OAM Bypass
ˆ OAM Visible
ˆ Link Test
For detailed information on the DIP switches, refer to “DIP Switch
Settings” on page 263. For information on the operating modes, refer
to “Configuring the Line Card Operating Mode” on page 67.
Display DIP Switch Setting
Module 5
DIP Switch Operating Mode: SML
Return to Module Status and Configuration ...
