To display line card status information, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 12 on page 53.
2. Select the line card whose information you want to display.
3. Press .
An example of the Module Configuration Menu for the AT-CM202 line
card is shown in Figure 13.
Figure 13. Module Configuration Menu (Line Card)
The Module Configuration Menu items and options are described
below:
Module
Displays the model number of the line card.
Port
Identifies the ports of the module.
Link
Displays the status of the link state on the ports. Possible values are:
ˆ Online - Indicates that there is a valid link.
ˆ Offline - Indicates that there is no link.
Speed
Displays the operating speed of the ports.
Possible values are:
Module Configuration Menu
Converteon
Module 4
Module: AT-CM202
Port Link Speed Mode
A(100BaseFX) Online 100M Full
B(100BaseTX) Online 10M Half
Configure Operating Mode
Display DIP Switch Setting
Return to Module Status and Configuration ...
