Chapter 3: Basic Parameters
32
The IP Parameters Menu is displayed, as shown in Figure 4.
Figure 4. IP Parameters Menu
3. Adjust the following parameters as necessary:
Location
The location can be up to 20 alphanumeric characters, including
spaces and special characters. To delete the current location without
entering a new location, press the space bar once.
Contact
The contact information can include the name, phone number, and
other information that identifies the person responsible for managing
the system. The contact information can be up to 20 alphanumeric
characters, including spaces and special characters. To delete the
current contact without entering new information, press the space bar
once.
4. From the Main Menu, select System Configuration.
The System Configuration Menu is displayed, as shown in Figure 3 on
page 29.
5. From the System Configuration Menu, select Save Configuration
File.
IP Parameters Menu
Converteon
IP address:
10.0.0.1
Subnet mask:
255.255.252.0
Gateway address:
0.0.0.0
Manager address:
0.0.0.0
Manager address:
0.0.0.0
Manager address:
0.0.0.0
Manager address:
0.0.0.0
Get community string:
public
Set community string:
private
Trap community string:
public
Location:
California USA
Contact:
Allied Telesis
> Disable DHCP
Enable DHCP
Return to System Configuration Menu...
