Chapter 9: SNMPv3
160
The Configure SNMPv3 View Table menu is displayed, as shown in
Figure 65.
Figure 65. Configure SNMPv3 View Table Menu
4. From the Configure SNMPv3 View Table menu, select Create
SNMPv3 Table Entry.
The following prompt is displayed:
Enter View Name:
5. Enter a descriptive name of this View.
Enter a unique name of up to 32 alphanumeric characters.
Note
The “defaultViewAll” value is the default entry for the SNMPv1 and
SNMPv2c configuration. You cannot use the default value for an
SNMPv3 View Table entry.
The following prompt is displayed:
Enter View Subtree (OID format/Text Name):
6. Enter the subtree that this view will or will not be permitted to display.
You can enter either a numeric value in hex format or the equivalent
text name. For example, the OID hex format for TCP/IP is:
1.3.6.1.2.1.6
The text format is for TCP/IP is:
tcp
The following prompt is displayed:
Enter Subtree Mask (Hex format):
Configure SNMPv3 View Table
Converteon
Create SNMPv3 Table Entry
Delete SNMPv3 Table Entry
Modify SNMPv3 Table Entry
Display SNMPv3 Table Entry
Return to SNMPv3 Configurations ...
