Chapter 8: Operations, Administration, and Maintenance (OAM)
132
The OAM Configuration Menu is displayed, as shown in Figure 49 on
page 117.
7. From the OAM Configuration Menu, select the OAM Loopback Test
Menu.
The OAM Loopback Test Menu is displayed, as shown in Figure 54 on
page 130.
8. From the OAM Loopback Test Menu, select Show Loopback Test
Statistics to display the current loopback test statistics, or select
Clear Loopback Test Statistics to clear all current loopback test
statistics.
If Show Loopback Test Statistics is selected, the Show Loopback Test
Menu is displayed, as shown in Figure 55, showing the current
loopback test statistics.
Figure 55. Show Loopback Test Statistics Menu
9. From the Main Menu, select System Configuration.
The System Configuration Menu is displayed, as shown in Figure 10
on page 46.
10. From the System Configuration Menu, select Save Configuration
File.
Show Loopback Test Statistics
Module = 5, Port = 1
Number of Seconds 0
Number of Tx Frames 0
Number of Rx Frames 0
Number of Rx Errored Frames 0
Number of Tx Bytes 0
Number of Rx Bytes 0
Number of Rx Errored Bytes 0
Number of Tx Bits 0
Number of Rx Bits 0
Number of Rx Errored Bits 0
Return to OAM Loopback Test...
