Chapter 8: Operations, Administration, and Maintenance (OAM)
130
The OAM Loopback Test Menu is displayed, as shown in Figure 54.
Figure 54. OAM Loopback Test Menu
8. From the OAM Loopback Test Menu, select Enable Remote
Loopback to enable the remote loopback, or select Disable Remote
Loopback to disable the remote loopback test. The default is
disabled.
When remote loopback is enabled, the local MAC Client stops sending
data frames to the remote station and the local OAM Client sets its
action parameter to DISCARD.
9. From the Main Menu, select System Configuration.
The System Configuration Menu is displayed, as shown in Figure 10
on page 46.
10. From the System Configuration Menu, select Save Configuration
File.
Starting or
Stopping a
Loopback Test
To start or to terminate the OAM loopback test, perform the following
procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 46 on page 115.
2. Select the line card whose loopback test you want to start or stop.
3. Press .
The Module Configuration Menu is displayed, as shown in Figure 47
on page 116.
4. Select the port whose loopback test you want to start or stop.
OAM Loopback Test
Module = 5, Port = 1
Enable Remote Loopback
> Disable Remote Loopback
Start Loopback Test
> Stop Loopback Test
Show Loopback Test Statistics
Clear Loopback Test Statistics
Return to OAM Configurations ...
