Chapter 5: Working with Line Cards
78
Channel (1 to 4) , Sub-Menu 1
When one of these parameters is selected, the TDM Channel
Configuration Menu 1 is displayed, as shown in Figure 26.
Figure 26. TDM Channel Configuration Menu 1
Configure the TDM channel of the selected AT-CM70S line card to:
ˆ Long Haul (default)
Limited Long Haul
ˆ T1 DSX-1(0 to 133ft)/0dB CSU (default)
T1 DSX-1(133 to 266ft)
T1 DSX-1(266 to 399ft)
T1 DSX-1(399 to 533ft)
T1 DSX-1(533 to 655ft)
T1 -7.5dB CSU
T1 -15dB CSU
T1 -22.5dB CSU
TDM Channel Configuration Menu 1
Module 15, Port C
> Long Haul
Limited Long Haul
> T1 DSX-1(0 to 133ft)/0dB CSU
T1 DSX-1(133 to 266ft)
T1 DSX-1(266 to 399ft)
T1 DSX-1(399 to 533ft)
T1 DSX-1(533 to 655ft)
T1 -7.5dB CSU
T1 -15dB CSU
T1 -22.5dB CSU
Return to LIU Mode and Channel Select Menu ...
