Chapter 8: Operations, Administration, and Maintenance (OAM)
116
The Module Configuration Menu is displayed, similar to the one in
Figure 47.
Figure 47. Module Configuration Menu (Line Card)
4. Select the port whose OAM operations you want to configure.
5. Press .
The Port Management Menu is displayed, as shown in Figure 48.
Figure 48. Port Management Menu
6. From the Port Management Menu, select OAM Configurations.
Module Configuration Menu
Converteon
Module 4
Module: AT-CM202
Port Link Speed Mode RX/ACT
A(100BaseFX) Online 100M Full Off
B(100BaseTX) ONline 10M Half Off
Configure Operating Mode
Return to Module Status and Configuration Menu...
Port Management Menu
Module 4 - Port A
Port Configurations
OAM Configurations
Return to Module Configuration Menu...
