Chapter 5: Working with Line Cards
82
Working with the AT-CV5M01 Management Card
The following sections describe operations related to the
AT-CV5M01Management Card:
ˆ “Displaying Port Status Information,” next
ˆ “Working with a Redundant AT-CV5M01 Management Card” on
page 83
ˆ “Resetting the AT-CV5M01 Management Card” on page 84
Displaying Port
Status
Information
The following procedure allows you to view the parameter settings of the
10/100Base-TX port on the AT-CV5M01 Management Card.
To display the status of an AT-CV5M01 Management Card, perform the
following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 12 on page 53.
2. Select the management card.
3. Press .
The Module Configuration Menu is displayed, as shown in Figure 29.
Figure 29. Module Configuration Menu (Management Card)
The Module Configuration Menu items and options are described
below:
Module
Displays the model number of the line card.
Module Configuration Menu
Converteon
Module 1
Module: AT-CV5M01
Port Link Speed Mode
A(100BaseTx) Online Auto Auto
Reset CPM and Restart System Software
Return to Module Status and Configuration Menu...
