AT-S70 Management Software User’s Guide
85
Working with the AT-CM2K0S Line Card
The AT-CM2K0SCM2K0S line card has several features not found on
other line cards. The following sections provide procedures for these
features:
ˆ “Configuring the Maximum Frame Size,” next
ˆ “Displaying Port Traffic Statistics” on page 86
ˆ “Setting the Port Ingress and Egress Rate Limits” on page 88
ˆ “Displaying the Port Ingress and Egress Rate Limits” on page 90
Configuring the
Maximum Frame
Size
To configure the maximum frame size, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 12 on page 53.
2. Select the AT-CM2K0S line card whose information you want to
change.
3. Press .
The Module Configuration Menu for the AT-CM2K0S line card is
displayed, as shown in Figure 31.
Figure 31. AT-CM2K0S Configuration Menu
Module Configuration Menu
Converteon
Module 14
Module: AT-CM2K0S
Port Link Speed Mode
1: A(1000Base SFP) Online Auto Auto
2: B(1000Base-T) Offline -- --
Configure Max Frame Size
Configure Operating Mode
Display DIP Switch Setting
Return to Module Status and Configuration Menu...
